EPR Rubber O-Ring for 2 Litre Pressure Pot ...

Fluid tanks keep a steady fluid pressure, eliminate fluid contamination and evaporation, and eliminate fumes. This EPR rubber O-Ring seals around the tank lid.

TS1258-VIT O-Ring for TS1258 Pressure Pot Techcon

This part code is for a replacement EPR rubber O-ring for the TS2220 pressure pot. The standard O-ring supplied with the pressure pot is EOR rubber and is intended for applications with lubricants, conductive and non-conductive adhesives and various other compounds not listed below. This O-ring may be cleaned with Toluene and/ or Isopropyl Alcohol.

WARNING: Do not soak O-ring in Toluene, MEK and Acetone. Read material safety data sheet for any solvent prior to use.

Spare O-ring. A kit is available made from EPR and is intended for applications using fluids containing UV adhesives, Cyanoacrylates (CAs), Methacrylates, and/or Acrylic Acids. If used, this O-ring may be cleaned as necessary with Isopropyl Alcohol, Acetone and MEK.

Please note: Occasionally and EPR O-ring will swell or degrade when in contact with some UV adhesives, Cyanoacrylates (CAs), Methacrylates and/or Acrylic Acids. This might be due to other components in the fluid product. The O-ring is easy to replace, fitted in the slot within the tank lid. 6mm Diameter.

EPR Rubber O-Ring Seal

GBP each ex. Vat.
Excludes carriage.

Product Code: PT2-OR
Lead Time: 24 Hours

Summary: EPR Rubber O-Ring replacement for TS2220 pressure pot only. Simple installation into tank lid recess.

Product Code	Qty	Price GBP	Add
PT2-OR	1	each

TS2220 Pressure Pot

GBP each ex. Vat.
Excludes carriage.

Product Code: TS2220
Lead Time: 24 Hours

Summary: Standard tank unit with lid, adjustable air pressure gauge, stainless steel tube fitting, 1/4" OD flexible tube, user guide. CE approved.

Product Code	Qty	Price GBP	Add
TS2220	1	each

	Part ID:	TS2220 or TS2220LS
	Materials:	Stainless Steel/ Aluminium
	Product Colour:	Silver Body/ Blue Lid
	Outer Dimensions:	128mm W x 185mm H
	Inner Tank Size:	120mm W x 177mm H
	Weight:	4.5 kg
	Maximum Pressure	Up to 75 PSI (5 Bar)
	Meets:	CE Approval
	Warranty:	1 Year

The level sensor assembly is available to order and retrofit to the standard TS2220 pressure pot. Part Code TS22LS. Price GBP each ex. Vat.

Items are shipped by a courier on a tracked and insured service for all items that are available from stock. Items on a lead time will be shipped as soon as they are available.

Tanks will handle low to medium viscosity liquids up to 35,000 CPS. Includes thin solvents, liquid, fluxes, flowable silicones, Cyanoacrylate, UV cure, inks, paints, lubricants, threadlockers & more.
