Complete bench top dispensing system for Cyanocrylate, UV Cure and other adhesives, liquids and glues. Use this setup hands free with the valve fixed in the stand. Can be positioned for height and angle. Pressure pot with gauge to set the most suitable flow rate. Digital controller unit for timed repeat shots or controlled beads. For dispensing as well as bottle filling.

Dispensing station for handling Cyanoacrylate adhesives and many other liquids up to 500 gram bottles (1 lb) of instant adhesive or other liquids placed inside. There is no pouring needed (ie: you can drop your bottle of glue right into the pressure pot). Very little clean-up is involved with this system and you do not smell the strong fumes of the glue as this is a contained system.

The valve is designed to dispense thin and medium viscosity cyanoacrylates with precise deposits of glue, with no dripping. The system has many ways to control the deposit: - needle size, tank pressure, - timer length control, - valve fine stroke adjustment. This system comprises of a valve, controller unit and pressure pot.

Buying a CA adhesive in a 500g sized bottle can be cost effective when compared to small 20g or 50g bottles. When applying adhesives by hand, it is slow and too much is often applied to each part which can create mess, waste and might damage some products. Or too little adhesive can be applied which creates a weak bond and part failure. With our system, the adhesive bottle is placed directly inside the compact tank unit and fed under very low air pressure down flexible feed tubing to the stand mounted diaphragm valve. The controller unit is then set to make micro dots, shots or beads each time the foot pedal is pressed. Its very simple to operate and maintain because all wetted parts are designed for use with CA's.

Dispensing tips are Teflon lined crimped to prevent rapid clogging of the adhesive. Using Teflon tips allows the operator to dispense CA adhesive without it blocking too quickly in between breaks or them having to replace tips too often. The same applies for automated machine applications such as a production line or cell where dispensing delays could see a need to repace inferior quality tips when dispensing CA's. Using our Teflon lined or full Teflon tips ensure that the application of CA’s is problem free. The systems comprises of a pressure pot to accept a 500g or smaller adhesive bottle.

A digital timed controller/ dispenser and a diaphragm valve with a benchtop stand to fix the valve in place for hands free dispensing. This dispensing system will ship with an extensive starter stock of Teflon tips, caps and fluid lines. The requirements for this system are a compressed air supply of 70-100 psi and a power supply of 220 V AC.
