> Home > Components > Tips > TE General Purpose Tips > TE722200PK




22 Gauge Dispensing Tip 2 Inch Long Tube ...

High quality stainless steel burr-free tube to moulded colour coded polypropylene hub with double-helix luer lock. Use this tip for dispensing adhesives, solvents, glues, primers, activators and others. A precision cut tube stainless shaft length of 2 Inch (50.8mm).

TE721150 21 gauge 1.5" long adhesive dispensing

TE needle series consist of a stainless-steel shaft with a double helix polypropylene hub. This premier line of dispensing needles is burr-free, and electro-polished shaft for unobstructed and consistent material flow.

Suitable for dispensing most fluids, adhesives and solvents. Certified silicone-free, chloride-free and industrial grade safe for use to 100 psi.

Tips are colour coded for gauge size. The tip features a tapered internal design where the shaft meets the hub to improve fluid flow and reduce restriction. This allows for a lower pressure to be used for dispensing gels and pastes.

Use with luer lock and luer slip syringes, air-powered dispensers, syringe barrels, bottles, fittings and dispensing shot valves. Silicone-free plastics ensure sensitive adhesives applied with these parts will not become contaminated during use.

All products shipped are in sealed boxes or packs that include label with batch codes.


Adhesive Dispensing Ltd provide a wide range of equipment options for dispensing almost all assembly fluids - from watery liquids, solvents, primers and activators through to thick pastes, sealants, silicones, gels and epoxies.

TE721200PK Tip 2 Inch Long

Excludes Carriage.
Lead Time:
Usually Ships 24 Hours

Summary: Dispensing nozzle tips blunt end stainless steel tube to poypro hub.

Item Qty Price GBP Add
TE721200PK 50   pack

Specifications

Materials: Polypro Hub, Stainless Steel Tube
Hub Colour: Purple
Tip Tube Length: 50.8mm (2 Inch)
Tip Tube ID: 0.51mm (0.020 Inch)
Tip Tube OD: 0.81mm (0.032 Inch)
Connection Type: Double Helix Luer Lock

Maximum Pressure: 100 PSI (6.89 Bar)
Flow Pattern: Straight
Description: General Purpose Tip
Features: Silicone-Free, Industrial Grade

Pack Sizes: 50


Delivery: Products shipped by courier on a tracked and insured service for stock items. Products on a longer lead time or built to order will be sent as soon as available. Customers are informed of ship dates. The items listed on this page are held in stock.

Typical Applications:- Deposits of solder paste or solder flux, grease to bearings, potting components with epoxies, RTV to edge seams, silicone shots to bond products, gasket sealant repair, aircraft maintenance work, braze pastes, solvents, threadlockers, general adhesive applications.


General Purpose Tips




  Adhesive dispensers     Syringe barrels   Dispensing tips
  Dispensers & Valve Controllers     Consumables
Syringes
  Dispensing
Tips


        Techcon Techkit cartridges
  Cartridges & Plungers     Dispensing Nozzles   Techkit Cartridges

  Literature

  Full Catalogue
  Syringe Barrels
  Cartridges & Nozzles
  Dispense Tips
  Nozzles Brochure
  Dispense Guns
  Dual Air Guns
  Dual Cartridge & Mixers

This product ships direct from stock


TE general purpose precision dispensing tips

Gauge Part Code Tube Length Pack OD mm ID mm Price Add
21 TE721025PK 6.35mm 50 0.81mm 0.51mm GBP
21 TE721050PK 12.70mm 50 0.81mm 0.51mm GBP
21 TE721100PK 25.40mm 50 0.81mm 0.51mm GBP
21 TE721150PK 38.10mm 50 0.81mm 0.51mm GBP
21 TE721200PK 50.80mm 50 0.81mm 0.51mm GBP
