Female to Male 1/4" Threaded Elbow Fitting
Our precision fittings offer safe and leak free connections from cartridges to barrels and feed tubing. This elbow adapter fitting has a male 1/4 Inch thread to connect to our cartridges. The female thread allows attachment of our TSD931-15 syringe filling adapter fitting.

TSD930-6 Elbow Fitting 1/4" Adhesive Dispensing Techcon


1/4 Inch thread to 1/4 Inch threaded elbow fitting.  Stainless Steel.  Supplied in packs of 1. Suitable for use with cartridges and dispense valves.

Compatible with most adhesives, solvents, inks, gels, chemicals, silicones, primers and activators. Female to male threads.

When used with fitting TSD931-15, this fitting provides a syringe filling solution from cartridges. use with part with TSD931-296 when used with pre-filled 310ml silicones tubes. This fitting is safe for use to 100 psi pressure.

Adhesive Dispensing Ltd provide a wide range of equipment options for dispensing almost all assembly fluids - from watery liquids, solvents, primers and activators through to thick pastes, sealants, silicones, gels and epoxies.


Purchase: TSD930-6S Fitting

GBP   each ex. Vat.
Excludes carriage.
Lead Time:
Ships Within 24 to 48 Hours

Product Code Qty Price GBP Add
TSD930-6S 1   each

Specifications

Material: Stainless Steel
Thread Inlet: 1/4 Inch Male
Thread Outlet: 1/4 Inch Female

Length: 1.0 Inch
Maximum Pressure: 100 PSI (6.89 Bar)
Flow Pattern: 90 Degree
Description: Universal Adapter Fitting
Features: Silicone-Free, Industrial Grade

Pack Size: 1


Fittings are robust and handle most liquids and pastes dispensed from them.

Items are shipped in the UK by a courier on a next day tracked and insured service for all products that are available from stock. Items on a lead time will be shipped as soon as they are made available. Overseas shipments are by tracked courier either UPS, DHL or FedEx.

These parts are available in larger packs on request.

Common Uses: Fittings are used with cartridges, dispense valves, manifolds, pressure pots.

Typical Applications:- These fittings are suitable for use with adhesives, solvents, pastes, gels, oils, inks, lubricants and many other materials.


Adhesive Dispensing Ltd provide a wide range of equipment options for dispensing almost all assembly fluids - from watery liquids, solvents, primers and activators through to thick pastes, sealants, silicones, gels and epoxies.
