Precision Bend 90 Degree Dispense Tip 22 Gauge 0.5 Inch Tube
Precision stainless steel burr-free tube
to moulded colour coded polypropylene hub with double-helix luer
lock. Use this tip for dispensing adhesives, solvents, glues,
primers, activators and other liquids. A bent stainless shaft
length of 0.50 Inch. UV filter hub protects UV cure adhesives.
The TE
needle series consist of a stainless-steel shaft with a double helix
polypropylene hub. This premier line of dispensing needles is burr-free,
and electro-polished shaft for unobstructed and consistent material
flow. Suitable for dispensing most fluids, adhesives and solvents.
Certified silicone-free, chloride-free and industrial grade safe for use
to 100 psi. Supplied in sealed packs of 50, 500 or 1000.
Tips are
colour coded for gauge size. The tip features a tapered
internal hub design where the shaft meets the hub to improve
fluid flow and reduce any restriction. This allows for a
lower pressure to be used for dispensing liquids and
pastes. These items ship direct from stock.
All products shipped are in sealed boxes or packs
that
include label with batch codes.
Adhesive Dispensing Ltd provide a wide range
of equipment options for dispensing almost all assembly fluids -
from watery liquids, solvents, primers and activators through to
thick pastes, sealants, silicones, gels and epoxies.
TE722050B90PK Tip
Excludes
Carriage. Lead Time: Ships Within 24 Hours
Summary: Precison
angled dispensing nozzle
tips blunt end stainless steel tube to poypro hub.
Item
Qty
Price
GBP
Add
TE722050B90PK
50
pack
TE722050B90P
500
pack
TE722050B90
1000
pack
Specifications
Materials: Polypro Hub, Stainless Steel
Tube Hub Colour: Blue
Tip
Tube
Length: 12.7mm (0.50 Inch) Tip Tube ID: 0.41mm (0.016 Inch) Tip Tube
OD: 0.71mm (0.028
Inch) Connection Type: Double Helix Luer Lock Maximum Pressure: 100 PSI (6.89 Bar) Flow Pattern: 90 Degree Description: Angled Bent Tip
Features: Silicone-Free, Industrial Grade
Pack Sizes: 50, 500 or 1000 MPN: AD72205090 Commodity Code: 90289090
Delivery: Products
shipped by courier on a tracked and
insured service for stock items. Products on a
longer
lead time or built to order will be sent as soon as available. Customers are informed of
ship dates. The items listed on this
page are held in stock.
Typical Applications:- Deposits
of solder paste or solder flux, grease to bearings, potting
components with epoxies, RTV to edge seams, silicone shots to bond
products, gasket sealant repair, aircraft maintenance work, braze
pastes, solvents, threadlockers, general
adhesive applications.
