TES Series Crimped Hub Precision Dispensing Tips
Offering the widest range of dispensing tips for use with syringe barrels, dispense bottles, dispense valves and robots. All tips are industrial grade safe for use to 100 psi air pressures and are certified silicone-free. Luer lock secure attachment for leak free dispensing. These crimped tips have a colour coded luer lock plastic hub that is crimped to a stainless steel tube. Ideal for solvents and UV cure glue.
TES18-1 Crimped TS Tip 18 Gauge Green 1" Long

The TES Series dispensing tips offer a variety of dispensing performance and flexibility options. Stainless steel tubing is cut to precise lengths and ground to be burr-free. Cut tubing is crimped into aluminium locking insert, then moulded into polyethylene hubs. Moulded hub colours correspond to gauge size. Products ship direct from stock.

All TES Series tips secure to syringe barrels and correspond to the double helix luer lock specification. Plastic crimped hubs are ideal for use with solvents and solvent based glues. All needle tips are safe to use up to 100 psi air pressure. They are supplied in standard packs of 50 or in bulk packs of 1000 tips. Suitable for use with all syringe barrels and dispense bottles including luer lock (twist on) and luer slip (push on) types for both pneumatic and manual dispensing.

For use with all luer lock and luer slip syringes, air-powered dispensers, syringe barrels, bottles, fittings and dispensing metering valves. Silicone-free plastics ensure sensitive or specialist adhesives applied using these parts will not become contaminated in use. Select the length of tube required and the gauge size (diameter). These tips are ideal for solvents and solvent based glues.


Specifications:

Materials: Polypro Hub, Stainless Steel Tube
Tube Lengths: 0.50", 1.0"
Tip Tube ID: 1.6mm to 0.21mm ID
Tip Tube OD: 1.83mm to 0.41mm OD
Tube Type: Blunt End
Tube Assembly: Aluminium Crimp Fixed
Connection Type: Double Helix Luer Lock

Maximum Pressure: 100 PSI (6.89 Bar)
Flow Pattern: Straight
Description: General Purpose Tip
Features: Silicone-Free, Industrial Grade

Pack Sizes: 50, 500 or 1000
Manufacturer: ADL
Commodity Tariff Code: 90289090
Lead Time: Ships Within 24 Hours

  Tip Info
  Brochure
  Full Catalog

Suitable for ...
Make dots of adhesives General Adhesives & Glues
Make beads of adhesives Flowable Silicones
Potting of components Epoxies & Resins
Sealing of components Threadlocker Adhesives
Dispense lubricants and greases Greases & Lubricants
UV Cure Adhesives
Solder Pastes & Fluxes



  Precision burr free blunt stainless tubing
  Two tube lengths and wide range of diameters
  Silicone free safe plastics - no contamination
  Safe for use up to 100 psi fluid pressures
  Luer lock colour coded hubs
  UV filtered plastic hubs for UV adhesives
  Crimped hubs ideal for aggresive solvents

  In sealed boxes of sealed bulk packs

Adhesive Dispensing Ltd provide a wide range of equipment options for dispensing almost all assembly fluids - from watery liquids, solvents, primers and activators through to thick pastes, sealants, silicones, gels and epoxies.



0.50" Long - 12.70mm Long Tube

14 gauge crimped dispensing tip luer lock 1/2"

  0.50 Inch Long Blunt End Precision Tips
Supplied in packs of 50, 500 or 1000


Precision dispensing tip. Stainless steel tube shaft to polypropylene colour coded luer lock hub. 1/2 Inch long tube (12.70mm). Certified silicone-free and industrial grade safe. Supplied in sealed boxes direct from stock.
Gauge Part Code Hub Colour Pack OD mm ID mm Price GBP Add
14 TES14-1/2 Olive 50 1.83mm 1.60mm GBP
14 TES14-500 Olive 500 1.83mm 1.60mm GBP
14 TES14-1000 Olive 1000 1.83mm 1.60mm GBP

Gauge Part Code Hub Colour Pack OD mm ID mm Price GBP Add
15 TES15-1/2 Grey 50 1.65mm 1.37mm GBP
15 TES15-500 Grey 500 1.65mm 1.37mm GBP
15 TES15-1000 Grey 1000 1.65mm 1.37mm GBP

Gauge Part Code Hub Colour Pack OD mm ID mm Price GBP Add
18 TES18-1/2 Green 50 1.27mm 0.84mm GBP
18 TES18-500 Green 500 1.27mm 0.84mm GBP
18 TES18-1000 Green 1000 1.27mm 0.84mm GBP

Gauge Part Code Hub Colour Pack OD mm ID mm Price GBP Add
20 TES20-1/2 Pink 50 0.91mm 0.61mm GBP
20 TES20-500 Pink 500 0.91mm 0.61mm GBP
20 TES20-1000 Pink 1000 0.91mm 0.61mm GBP

Gauge Part Code Hub Colour Pack OD mm ID mm Price GBP Add
21 TES21-1/2 Purple 50 0.81mm 0.51mm GBP
21 TES21-500 Purple 500 0.81mm 0.51mm GBP
21 TES21-100 Purple 1000 0.81mm 0.51mm GBP

Gauge Part Code Hub Colour Pack OD mm ID mm Price GBP Add
22 TES22-1/2 Blue 50 0.71mm 0.41mm GBP
22 TES22-500 Blue 500 0.71mm 0.41mm GBP
22 TES22-1000 Blue 1000 0.71mm 0.41mm GBP

Gauge Part Code Hub Colour Pack OD mm ID mm Price GBP Add
23 TES23-1/2 Orange 50 0.64mm 0.33mm GBP
23 TES23-500 Orange 500 0.64mm 0.33mm GBP
23 TES23-1000 Orange 1000 0.64mm 0.33mm GBP

Gauge Part Code Hub Colour Pack OD mm ID mm Price GBP Add
25 TES25-1/2 Red 50 0.51mm 0.25mm GBP
25 TES25-500 Red 500 0.51mm 0.25mm GBP
25 TES25-1000 Red 1000 0.51mm 0.25mm GBP

Gauge Part Code Hub Colour Pack OD mm ID mm Price GBP Add
27 TES27-1/2 Clear 50 0.41mm 0.21mm GBP
27 TES27-500 Clear 500 0.41mm 0.21mm GBP
27 TES27-1000 Clear 1000 0.41mm 0.21mm GBP

1.00" Long - 25.40mm Long Tube

TS Crimped aluminum luer dispensing tip

  1.0 Inch Long Blunt End Precision Tips
Supplied in packs of 50, 500 or 1000


Precision dispensing tip. Stainless steel tube shaft to polypropylene colour coded luer lock hub. 1.0 Inch long tube (25.40mm). Certified silicone-free and industrial grade safe. Supplied in sealed boxes direct from stock.
Gauge Part Code Hub Colour Pack OD mm ID mm Price GBP Add
14 TES14-1 Olive 50 1.83mm 1.60mm GBP
14 TES14-1 Olive 500 1.83mm 1.60mm GBP
14 TES14-1 Olive 1000 1.83mm 1.60mm GBP

Gauge Part Code Hub Colour Pack OD mm ID mm Price GBP Add
15 TES15-1 Grey 50 1.65mm 1.37mm GBP
15 TES15-1-500 Grey 500 1.65mm 1.37mm GBP
15 TES15-1-1000 Grey 1000 1.65mm 1.37mm GBP

Gauge Part Code Hub Colour Pack OD mm ID mm Price GBP Add
18 TES18-1 Green 50 1.27mm 0.84mm GBP
18 TES18-1-500 Green 500 1.27mm 0.84mm GBP
18 TES18-1-1000 Green 1000 1.27mm 0.84mm GBP

Gauge Part Code Hub Colour Pack OD mm ID mm Price GBP Add
20 TES20-1 Pink 50 0.91mm 0.61mm GBP
20 TES20-1-500 Pink 500 0.91mm 0.61mm GBP
20 TES20-1-1000 Pink 1000 0.91mm 0.61mm GBP

Gauge Part Code Hub Colour Pack OD mm ID mm Price GBP Add
21 TES21-1 Purple 50 0.81mm 0.51mm GBP
21 TES21-1-500 Purple 500 0.81mm 0.51mm GBP
21 TES21-1-1000 Purple 1000 0.81mm 0.51mm GBP

Gauge Part Code Hub Colour Pack OD mm ID mm Price GBP Add
22 TES22-1 Blue 50 0.71mm 0.41mm GBP
22 TES22-1-500 Blue 500 0.71mm 0.41mm GBP
22 TES22-1-1000 Blue 1000 0.71mm 0.41mm GBP

Gauge Part Code Hub Colour Pack OD mm ID mm Price GBP Add
23 TES23-1 Orange 50 0.64mm 0.33mm GBP
23 TES23-1-500 Orange 500 0.64mm 0.33mm GBP
23 TES23-1-1000 Orange 1000 0.64mm 0.33mm GBP

Gauge Part Code Hub Colour Pack OD mm ID mm Price GBP Add
25 TES25-1 Red 50 0.51mm 0.25mm GBP
25 TES25-1-500 Red 500 0.51mm 0.25mm GBP
25 TES25-1-1000 Red 1000 0.51mm 0.25mm GBP

Gauge Part Code Hub Colour Pack OD mm ID mm Price GBP Add
27 TES27-1 Clear 50 0.41mm 0.21mm GBP
27 TES27-1-500 Clear 500 0.41mm 0.21mm GBP
27 TES27-1-1000 Clear 1000 0.41mm 0.21mm GBP



Delivery: Products shipped by courier on a tracked and insured service for stock items. Products on a longer lead time or built to order will be sent as soon as available. Customers are informed of ship dates.

Typical Applications:- Deposits of solder paste, deposits of solder flux, grease to bearings, potting components with epoxy, RTV to edge seams, silicone shots to bond products, gasket sealant repair, aircraft maintenance work, braze pastes, solvent glues, liquids, general adhesive applications.

TES Crimped Precision Tips

TES21-1/2 Crimped Tip 1/2" Adhesive Dispensing

Copyright  2008 Adhesive Dispensing Ltd. All rights reserved. Syringe barrels Dispensing tips
Cartridges & Plungers Dispensing Nozzles Tip Caps Consumable Syringes Dispensing Tips


  COMPANY INFORMATION SUPPORT CUSTOMER SERVICE
  About Us Solutions Carriage
  Shipping & Returns FAQ's Terms & Conditions
  Privacy Site Map Help
  Contact Us Assist Accounts


Air-Powered Dispensers * Industrial Dispensing Components * Precision Dispense Valve Systems * Bench Robots

Adhesives * Packaged Components * Techkits * RatioPacks * Hingepacks * Syringe Barrels * Cartridges * Nozzles




Prices are in GBP pounds.  Vat is charged on all UK orders. We provide VAT invoices with all transactions. Vat is not charged on any orders placed with us that ship outside the UK and EU. No VAT is charged for any orders placed for shipment to the EU only if a valid company VAT number is provided to us at time of order or prior to shipping.  Products are covered by a 12-month warranty against all faults and malfunction.  All orders placed online are encrypted for total safety and security.  Additional encryption now protects all of the web pages on this site. Please read our privacy agreement for details of how we conform to GDRP.  We can also process any phone or fax payments by credit and debit cards.  Please contact our accounts department if you would like to apply for a 30 day credit account with us.

Disclaimer: While reasonable efforts have been made to ensure all information on this website is accurate, Adhesive Dispensing Ltd. do not assume responsibility for any errors or omissions. All specifications, illustrations, data and prices are subject to change without notice.

Copyright  2020 Adhesive Dispensing Ltd. All rights reserved.



  Literature
  Data Sheet
  Full Catalogue
  Dispensing Catalogue
  Syringe Barrels
  Cartridges & Nozzles
  Dispense Tips
  Dispense Guns
  Dual Air Guns
  Dual Cartridge & Mixers

  Information
  Tip Selector Guide
  Safety Information
  Viscosities Chart
  ISO9001:2015 Certificate
  ROHS & REACH



  Contact Us
  Equipment Recommendations
  Request a Quote
  Technical Support
  Applicator Assist

  Industrial Grade Safe


All products are safe for use for industrial applications. The components are leak-free and supplied in sealed packaging to prevent contamination.



  Silicone Free Products


Products including air powered barrels, cartridges, nozzles, luer tips, fluid lines, tubing, caps and seals - are certified silicone free to prevent contamination of sensitive adhesives dispensed from them.



  Using these products
  Dispensing tips are designed to work with all luer lock and luer slip syringe barrels and fittings. They are fully compatible with most fluids, adhesives, pastes and gels and useful for medium viscosity pastes, sealants, silicones, mastics, solder pastes as well as liquids, solvent based glues, primers, activators, PVA glues, compounds.

  Industrial Grade Safe
  All tips are safe for use up to 100 psi pressure. These non sterile tips are not for use on people or animals but are precision manufactured and moulded for industrial fluid applications.

  Silicone-Free Components
  Tips are certified silicone-free components to ensure they do not contaminate any fluids or sensitive adhesives that are dispensed from them and in contact with them.
