B-System Dual Cartridges & Static Mixer Nozzles |
|
High density dual component dispense cartridges for two part
adhesives, epoxies, silicones and other fluids. All sets are
supplied with matching pistons and a tip cap ready for filling and
dispensing. These are manual applicators supplied with plunger rods
and pistons ready for a choice of mix nozzle. Components are certified industrial grade
safe and
silicone free. The B-system has a twist-cap
nozzle attachment and part (A) and part (B) of the resin is fed
from separate outlet holes. |
|
 |
|
Polypropylene body cartridges used for
two component material mixing and dispensing without the need to manually
weigh, mix and pour. These products are compatible with B-System static
mixer nozzles.
Each cartridge set
includes the cartridge, dual pistons and a tip cap seal. Dual
system 25ml size 1:1 mix ratio by volume. Materials are filled and stored
in the two separate chambers of the cartridge system and dispensed simultaneously
into the static mixer where dynamic mixing
takes place. Use with 2-part epoxies, resins,
sealants, silcones & polyurethanes.
This cartridge is
manufactured from polypropylene so will resist most chemicals and
solvents. The 25ml kits come with the following parts:
(50) Cartridge 1:1 with volume capacity of 25ml maximum.
(50) Manual
plunger rods with piston wipe ends.
(50) Dust tip cap seal.
All products shipped are in sealed boxes or packs
that
include label with batch codes.
Specification:
Material: Polypropylene Barrel
Body
Colour: White
Plunger Colour: Natural
Nozzle Attachment: Grey Cap Twist-On
Mix Ratio: 1:1 By Volume
Flow Pattern: Straight
Description: Dual Cartridge
Features: Silicone-Free/ Industrial Grade
Commodity Code: 39269097
Brand: Sulzer Mixpac Medmix
Origin: Europe
Adhesive Dispensing Ltd provide a wide range of equipment
options for dispensing almost all assembly fluids - from
watery liquids, solvents, primers and activators through to
thick pastes, sealants, silicones, gels and epoxies.
|
|
|
B-System 25ml 2k Manual Syringe Sets |
 |
|
Dual 25ml manual
syringes for use
with 2-part epoxies, polyurethanes, potting
compounds, silicones, doming resins and other mixed materials. In 1:1 ratio by volume.
We supply in sealed packaging with detailed product
labels and batch codes. These syringes and mix
nozzles are for use manually by hand only. Commodity Code
39269097. |
|
|
Size |
Mix Ratio |
Body |
Part Code |
Lead Time |
Price GBP |
Add |
|
25ml |
1:1 |
Polypropylene |
116647 |
in stock |
pk/50 |
 |
|
25ml |
1:1 |
Polyamide |
116649 |
in stock |
pk/50 |
|
|
25ml |
1:1 |
Polypropylene |
116924 |
in stock |
pk/50 |
|
|
|
B-System Bayonet Mixer Nozzles |
 |
| The B-system
nozzles use a locking cap
attachment to the cartridge. Available in a wide
range of diameters and lengths. Helical round
version or quadro square body with green
elements. Nozzles outer is
made of natural high density polypropylene.
S have stepped end. T have tapered end. L have
luer end. D have open end. White and green for
1:1/2:1 and orange for 4:1/10:1. Click
the links below for more product details and
pack size options. Commodity tariff code
39269097. |
|
|
Dia. |
Length |
Element |
Ratio |
Colour |
Code |
Lead Time |
Price GBP |
Add |
|
3.2mm |
64mm |
12 |
1:1/2:1 |
White |
MBH03-12S |
in stock |
pk/100 |
|
|
3.2mm |
58mm |
12 |
1:1/2:1 |
White |
MBH03-12D |
in stock |
pk/100 |
|
|
3.2mm |
76mm |
16 |
1:1/2:1 |
White |
MBH03-16L |
in stock |
pk/100 |
|
|
3.2mm |
77mm |
16 |
1:1/2:1 |
White |
MBH03-16S |
in stock |
pk/100 |
|
|
4.2mm |
70mm |
12 |
1:1/2:1 |
White |
MBH04-12D |
in stock |
pk/100 |
|
|
4.2mm |
87mm |
16 |
1:1/2:1 |
White |
MBH04-16D |
in stock |
pk/100 |
|
|
4.2mm |
96mm |
16 |
1:1/2:1 |
White |
MBH04-16S |
in stock |
pk/100 |
|
|
5.4mm |
60mm |
6 |
1:1/2:1 |
White |
MBH05-06T |
in stock |
pk/100 |
|
|
5.4mm |
83mm |
12 |
1:1/2:1 |
White |
MBH05-12D |
in stock |
pk/100 |
|
|
5.4mm |
112mm |
14 |
1:1/2:1 |
White |
MBH05-14D |
in stock |
pk/100 |
|
|
5.4mm |
112mm |
16 |
1:1/2:1 |
White |
MBH05-16T |
in stock |
pk/100 |
|
|
5.4mm |
133mm |
20 |
1:1/2:1 |
White |
MBH05-20T |
in stock |
pk/100 |
|
|
6.5mm |
89mm |
11 |
1:1/2:1 |
White |
MBH06-11D |
in stock |
pk/100 |
|
|
6.5mm |
131mm |
16 |
1:1/2:1 |
White |
MBH06-16T |
in stock |
pk/100 |
|
|
6.5mm |
157mm |
20 |
1:1/2:1 |
White |
MBH06-20T |
in stock |
pk/100 |
|
|
5.3mm |
91mm |
16 |
1:1/2:1 |
Green |
MBQ05-16L |
in stock |
pk/100 |
|
|
5.3mm |
122mm |
24 |
1:1/2:1 |
Green |
MBQ05-24L |
in stock |
pk/100 |
|
|
|
|
Industrial Grade Safe
Silicone-Free - no contamination
Supplied
in sealed packs - batch codes
Handles
epoxies, silicones, PUs, etc
Quick
attach static mixer nozzles
Competitive pricing for these items |
|
|
Delivery: Products shipped by courier on a tracked and
insured service for stock items. Products on a longer lead time or built to
order will be sent as soon as available. Customers are informed of ship
dates.
Typical
Applications:- Deposits of epoxy resins, silicones, potting
compounds, polyurethanes and other 2-part materials. |
|
|
|
|
|
Gun Dispensers for Dual Component Cartridges |
 |
|
Gun dispensers for use with 50ml, 150ml 200ml, 300ml,
400ml, 600ml, 1200ml and 1500ml dual cartridge components. Manual,
pneumatic and battery rechargeable versions. For mix ratios 1:1,
2:1, 4:1 and 10:1. Rod driven applicators for controlled deposits
with material mess or waste. Easy to use products supplied with user
guides. Read more... |
|
|
Dual Component Cartridges and Static Mixer Nozzles |
 |
|
Industrial twin tube cartridges for use with epoxy
resins, polyurethanes, silicones and doming resins. In sizes 2.5ml,
3ml, 5ml, 10ml, 25ml, 50ml, 200ml, 400ml and 600ml. With wiper
pistons vented or lip-seal. In white polyethylene colour. Different
versions are available direct from stock. Wide range of
mix nozzles
are available. Read more... |
|
|
Static Mixer Nozzles |
 |
|
We stock a wide range of static mix nozzles for use
with two component cartridges and high pressure machine mixers. To
suit the different dual cartridge sizes
of K-System, A-System, B-System, C-System, F-System. And machines
types ME and MS series mixers. As well as the square Quadro mixers
and luer lock nozzles.
Read more... |
|
|
Air Powered Syringe Barrel Dispensers |
 |
|
We stock a wide range of pneumatic dispensers for use
with 3cc, 5cc, 10cc, 30cc, 55cc size syringe barrels and new 100cc,
200cc, 300cc, 400cc and 500cc big barrels. Dispensers can provide
timed shots of liquids and paste eliminating hand fatigue,
inconsistency and mess. Select from analog timed dispensers to full
digital with memory and auto repeat.
Read more... |
|
|
|
|
|
Air-Powered Dispensers * Industrial Dispensing Components *
Precision Dispense Valve Systems * Bench Robots |
|
Adhesives * Packaged Components * Techkits * RatioPacks *
Hingepacks * Syringe Barrels * Cartridges * Nozzles |
|
