400ml Pneumatic Cartridge Gun for Epoxy Dispensing

Our cartridge gun dispensers are designed for the controlled application of two component epoxies, silicones and other materials. Use this high quality applicator gun with 1:1, 2:1, 4:1 or 10:1 ratio 400ml dual cartridges.

Pneumatic dual cartridge gun


For epoxies, adhesives and other materials that are supplied in 400ml two part, side-by-side 1:1, 2:1. 4:1 and 10:1 ratio cartridges with the use of a static mixing nozzle.

The lightweight and durable construction of our pneumatic dual guns make them well suited for many assembly operations in various markets such as aerospace, electronics, construction and automotive.

The dual cartridge is pushed into the side retainer of the gun. The trigger is pressed pushing the rods onto the pistons within the cartridge. Features an adjustable air regulator to set the flow rate.

Supplied with discs to quickly change the setup for different mix ratio cartridges.



More Info Part No. Size Type Ratio Details Price GBP Add
CG200 epoxy pneumatic adhesive dispensing gun CG400-2
Multi Ratio Dual Gun
400ml Air Gun 1:1/2:1/ 4:1/10:1 Gun Only    each
200ml 1:1 Ratio Dual Cartridge System 400011
Dual Cartridges
400ml Cartridge Piston Sets 1:1 Only With Pistons    pack 50
200ml 1:1 Ratio Dual Cartridge System 400021
Dual Cartridges
400ml Cartridge Piston Sets 2:1 Only With Pistons    pack 50
200ml 1:1 Ratio Dual Cartridge System 400041
Dual Cartridges
400ml Cartridge Piston Sets 4:1 Only With Pistons    pack 50
200ml 1:1 Ratio Dual Cartridge System 400101
Dual Cartridges
400ml Cartridge Piston Sets 10:1 Only With Pistons    pack 50
Static Mixer Nozzle Adhesive Dispensing MC05-18
Static Mixer Nozzle
5.0mm 121mm Long x 18 Elements 1:1/2:1 Bell Mouth Top
White Element
   pack 100
Static Mixer Nozzle Adhesive Dispensing MC05-24
Static Mixer Nozzle
5.0mm 149mm Long x 24 Elements 1:1/2:1 Bell Mouth Top
White Element
   pack 100
Static Mixer Nozzle Adhesive Dispensing MC06-24
Static Mixer Nozzle
6.0mm 185mm Long x 24 Elements 1:1/2:1 Bell Mouth Top
White Element
   pack 100
Static Mixer Nozzle Adhesive Dispensing MC06-32
Static Mixer Nozzle
6.0mm 234mm Long x 32 Elements 1:1/2:1 Bell Mouth Top
White Element
   pack 100
Static Mixer Nozzle Adhesive Dispensing MC08-18
Static Mixer Nozzle
8.0mm 177mm Long x 18 Elements 1:1/2:1 Bell Mouth Top
White Element
   pack 100
Static Mixer Nozzle Adhesive Dispensing MC08-24
Static Mixer Nozzle
8.0mm 223mm Long x 24 Elements 1:1/2:1 Bell Mouth Top
White Element
   pack 100
Static Mixer Nozzle Adhesive Dispensing MC10-18
Static Mixer Nozzle
10.0mm 214mm Long x 18 Elements 1:1/2:1 Bell Mouth Top
White Element
   pack 100
Static Mixer Nozzle Adhesive Dispensing MCHX08-18
Static Mixer Nozzle
8.0mm 182mm Long x 18 Elements 4:1/10:1 Bell Mouth Top
Orange Element
   pack 100
Static Mixer Nozzle Adhesive Dispensing MCHX08-24
Static Mixer Nozzle
8.0mm 230mm Long x 24 Elements 4:1/10:1 Bell Mouth Top
Orange Element
   pack 100
Static Mixer Nozzle Adhesive Dispensing MCHX10-12
Static Mixer Nozzle
10.0mm 155mm Long x 12 Elements 4:1/10:1 Bell Mouth Top
Orange Element
   pack 100
Static Mixer Nozzle Adhesive Dispensing MCHX10-18
Static Mixer Nozzle
10.0mm 215mm Long x 18 Elements 4:1/10:1 Bell Mouth Top
Orange Element
   pack 100
Static Mixer Nozzle Adhesive Dispensing MCHX10-24
Static Mixer Nozzle
10.0mm 275mm Long x 24 Elements 4:1/10:1 Bell Mouth Top
Orange Element
   pack 100
Static Mixer Nozzle Adhesive Dispensing MCHX13-12
Static Mixer Nozzle
13.0mm 192mm Long x 12 Elements 4:1/10:1 Bell Mouth Top
Orange Element
   pack 100

Product Pages


CG400-2 Gun Features
  Works with 400ml dual cartridges
  490 lbs thrust power at 100 psi pressure
  Adjustable air regulator
  Easily converts ratios in seconds
  Snap in/ snap out push discs
  Quick cartridge side load
  Counter balance hook ring
  Reverse rod mode for cartridge changeover
  Robust design for long life use
  Only 2.7 KG Weight
  Total length 21 inches
  Available direct from stock
  1 Year warranty - CE approved
